| 电容调理芯片 | ||||||||||||
| 型号 | 测量范围 | 工作温度范围 | 接口 | 测量速度 | 分辨率 | 供电电压 | 驱动方式 | 平均功耗 | MCU/存储 | 通道数 | 封装 | 其他 |
| MCP1081 | 1pF~10nF | -40℃~+85℃ |
I²C UART GPIO |
0.1~23.5ms | 16bit | 2.3V~5.5V |
0.1~30MHz 单端对地电容 双端浮空电容 互电容 |
12uA@1Hz |
32-bit Arm®Cortex®-M0 16KB FLASH |
10通道 | QFN24 | 首推 |
| MC1081 | 1pF~10nF | -55℃~+125℃ | I²C | 0.1~23.5ms | 16bit | 2.3V~5.5V |
0.1~30MHz 单端对地电容 双端浮空电容 互电容 |
2.5μA@1Hz | - | 10/4通道 |
QFN16 DFN8 TSSOP16 |
首推 |
| MCP61 | 1~1000pF | -40℃~+85 ℃ |
I²C UART SPI GPIO |
1~100ms | 16bit | 2.5V~5.5V |
0.1~20MHz 双端互电容 |
12uA@1Hz |
32-bit Arm®Cortex®-M0 16KB FLASH |
2通道 |
QSOP24 QFN24 |
|
| MC11 | 1~1000pF | -55℃~+125℃ | I²C | 1~100ms | 16bit | 2.0V~5.5V |
0.1~20MHz 差分电容 |
2.6μA@1Hz | - | 2通道 |
QFN16 TSSOP16 SOP8 |
|
| MCP62 | 1~150pF | -40℃~+85℃ |
I²C UART SPI GPIO |
1~100ms | 16bit | 2.5V~5.5V |
10~100MHz 单端对地电容 |
15μA@1Hz |
32-bit Arm®Cortex®-M0 16KB FLASH |
2通道 |
QSOP24 QFN24 |
|
| MC12 | 1~150pF | -55℃~+125℃ | I²C | 1~100ms | 16bit | 2.0V~5.5V |
10~100MHz 单端对地电容 |
7.5μA@1Hz | - | 2通道 |
SOP8 QFN16 |
|
| MDC04 | 1~119pF | -55℃~+125℃ |
单总线 I²C |
10.5ms/5.5ms/4ms | 16bit | 2.0V~5.5V |
10~100k 差分电容 |
5.3μA@1Hz | 48bit EEPROM | 4通道 |
QFN20 |
|
| MDC02 | 1~119pF | -55℃~+125℃ | 单总线 | 10.5ms/5.5ms/4ms | 16bit | 2.0V~5.5V |
10~100k 差分电容 |
5.3μA@1Hz | 48bit EEPROM | 2通道 | SOP8 | |
| 数字温度芯片 | ||||||||||||
| 型号 | 测温精度 | 测温范围 | 接口 | 测温速度 | 分辨率 | 供电电压 | I²C地址 | 平均功耗 | 用户空间E²PROM | 封装 | 其他 | |
| T117 | ±0.1℃±0.5℃ | -103℃~+153℃ |
I²C 单总线 |
15.3ms/8.5ms/5.2ms/2.2ms | 16bit,0.004℃ | 1.8V~5.5V |
0x40 0x41 0x42 0x43 |
2μA@3.3V，1Hz (AVG=8) |
112bit | DFN6L | 首推 | |
| T1601 | ±0.1℃±0.5℃ | -103℃~+153℃ | 单总线 | 15.3ms/8.5ms/5.2ms/2.2ms | 16bit,0.004℃ | 1.8V~5.5V | - |
2μA@3.3V，1Hz （AVG=8） |
112bit | SOT23-3 | 首推 | |
| T1820 | ±0.1℃±0.5℃ | -103℃~+153℃ | 单总线 | 15.3ms/8.5ms/5.2ms/2.2ms | 16bit,0.004℃ | 1.8V~5.5V | - |
2μA@3.3V，1Hz (AVG=8) |
112bit | TO92S | 首推 | |
| MTS4 |
±0.1℃ ±0.5℃ |
-103℃~+153℃ |
I²C 单总线 |
15.3ms/8.5ms/5.2ms/2.2ms | 16bit,0.004℃ | 1.8V~5.5V | 0x41 |
2μA@3.3V，1Hz (AVG=8) |
112bit | DFN4L | 首推 | |
| M117 |
±0.1℃ ±0.5℃ |
-70℃~+150℃ | I²C | 10.5ms/5.5ms/4ms | 16bit,0.004℃ | 1.8V~5.5V | M117:0x44 M117B:1x45 | 4.8μA@3.3V，1Hz | 32bit | DFN6L | ||
| M601 |
±0.1℃ ±0.5℃ |
-70℃~+150℃ | 单总线 | 10.5ms/5.5ms/4ms | 16bit,0.004℃ | 1.8V~5.5V | - | 4.8μA@3.3V，1Hz | 32bit | DFN8 | ||
| M1601 |
±0.1℃ ±0.5℃ |
-70℃~+150℃ | 单总线 | 10.5ms/5.5ms/4ms | 16bit,0.004℃ | 1.8V~5.5V | - | 4.8μA@3.3V，1Hz | 32bit | SOT23-3 | ||
| M1820 | ±0.1℃±0.5℃ | -70℃~+150℃ | 单总线 | 10.5ms/5.5ms/4ms | 16bit,0.004℃ | 1.8V~5.5V | - | 4.8μA@3.3V，1Hz | 32bit | TO92S | ||
| MTS01 | ±0.1℃±0.5℃ | -70℃~+150℃ |
I²C 单总线 |
10.5ms/5.5ms/4ms | 16bit,0.004℃ | 1.8V~5.5V |
0x44 1x45 |
4.8μA@3.3V，1Hz | 32bit | DFN8 | ||
| ±0.5℃ | -55℃~+125℃ | 单总线 | 500ms/15ms | 12bit,0.0625℃ | 1.8V~5.5V | - | 5μA@5V，1Hz | 80bit | TO-92 TO92S SOP8 MSOP8 TO92L | |||
| M401 | ±2℃ | -55℃~+200℃ | I²C | 25ms | 14bit,0.03125℃ | 2.5V~5.5V | - | 35μA@1Hz | 32bit | QFN16 | 4路远端+1路本地 | |
| M201 | ±2℃ | -55℃~+200℃ | I²C | 25ms | 14bit,0.03125℃ | 2.5V~5.5V | - | 35μA@1Hz | 32bit | SOP8 | 2路远端+1路本地 | |
| 电感调理芯片 | ||||||||||||
| 型号 | 电感测量范围 | 电容测量范围 | 温度范围 | 接口 | 测量速度 | 分辨率 | 供电电压 | 驱动方式 | 平均功耗 | 通道数 | 封装 | |
| MLC12G | 100nH~1mH | 0~100nF | -55℃~+125℃ | I²C | 1ms~100ms | 16bit | 2.0V~5.5V |
10K~100MHz 单端电容 单端电感 |
7.5μA@1Hz | 2通道 | QFN16 | |
| 电化学调理芯片 | |||||||||||||
| 型号 | 氮氧浓度量程 | 电控工作温度 | 接口 | 气体分辨率 | 氮氧浓度分辨率 | 供电电压 | 平均功耗 | CDM ESD | HBM ESD | 封装 | |||
| MY9706 | 0ppm~3000ppm | -55℃~+125℃ | SPI | 0.5ppm | 14bit ADC | 5V |
16mA |
±2kV | ±7kV | SSOP24 | |||
